应用
电磁屏蔽室，电波暗室，电子方舱，屏蔽机柜等设施
单相两线、三相四线制电源滤波器，16至200A
产品特征
体积紧凑，△V压降低，漏电流低
安装在屏蔽体上不需要焊接，安装简单
金属壳体采用特殊的不锈钢材质，机械强度高，耐腐蚀性强
特殊的界限结构设计，进线和出线可分别在打开的屏蔽腔体内接线，方便又安全
技术参数
| 额定电压VR | |
| 单相 | L To N: 250VAC |
| 三相 | L To L: 440VAC |
| L To N: 250VAC | |
| 额定频率 | 50/60Hz |
| 测试电压 | L To G: 1000VDC/2S |
| L To L: 1000VDC/2S | |
| 气候类别 | 25/70/21 |
| 多级滤波，抑制频段 14KHz to 40GHz | |
选型表
| 型号 | 额定电流 (A) | 额定电压 (V) | 漏电流 (A) | 插入损耗（dB） |
| TSSF-J201C1-16 | 2x16 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J201C1-32 | 2x32 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J201C1-50 | 2x50 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J201C1-63 | 2x63 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J201C1-100 | 2x100 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J201C1-200 | 2x200 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-16 | 4x16 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-32 | 4x32 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-50 | 4x50 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-63 | 4x63 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-100 | 4x100 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J401C1-200 | 4x200 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-16 | 2x16 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-32 | 2x32 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-50 | 2x50 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-63 | 2x63 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-100 | 2x100 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J211C1-200 | 2x200 | 250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-16 | 4x16 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-32 | 4x32 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-50 | 4x50 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-63 | 4x63 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-100 | 4x100 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
| TSSF-J411C1-200 | 4x200 | 440/250VAC | <0.2 | 100dB,1MHz~10/40GHz |
